G008962
Figure28
UsingtheDriveWheelRelease
Valves
WARNING
Handsmaybecomeentangledintherotatingdrive
componentsbelowtheenginedeck,whichcould
resultinseriousinjury.
Stoptheengine,removethekey,andallowall
movingpartstostopbeforeaccessingthedrive
wheelreleasevalves.
WARNING
Theengineandhydraulicdriveunitscanbecome
veryhot.Touchingahotengineorhydraulicdrive
unitscancausesevereburns.
Allowtheengineandhydraulicdriveunitstocool
completelybeforeaccessingthedrivewheelrelease
valves.
Thedrivewheelreleasevalvesarelocatedbehindthe
seatanddownintheenginecompartment.
1.DisengagethePTO(bladecontrolswitch)andturn
theignitionkeytooff.Movetheleverstoneutral
lockedpositionandapplyparkingbrake.Remove
thekey.
2.Locatethebypassleversbehindtheseat,downon
theleftandrightsideoftheframe.
3.Topushthemachine,movethebypasslevers
rearwardandouttolocktheminplaceasshownin
Figure29.Repeatthisoneachsideofthemachine.
4.Disengageparkingbrakebeforepushing.
g017420
2
3
4
1
Figure29
5.Torunthemachine,movethebypassleverstothe
forwardposition(
Figure29).
UsingtheSideDischarge
Themowerhasahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardtheturf.
DANGER
Withoutagrassdeector,dischargecover,or
completegrasscatcherassemblymountedin
place,youandothersareexposedtobladecontact
andthrowndebris.Contactwithrotatingmower
blade(s)andthrowndebriswillcauseinjuryor
death.
•Neverremovethegrassdeectorfromthe
mowerbecausethegrassdeectorroutes
materialdowntowardtheturf.Ifthe
grassdeectoriseverdamaged,replaceit
immediately.
•Neverputyourhandsorfeetunderthemower.
•Nevertrytoclearthedischargeareaormower
bladesunlessyoumovethepowertakeoff
(bladecontrolswitch(PTO)totheoffposition,
rotatetheignitionkeytooffandremovethekey.
•Makesurethegrassdeectorisinthedown
position.
LoadingMachines
Useextremecautionwhenloadingunitsontrailersor
trucks.Onefullwidthrampthatiswideenoughto
extendbeyondthereartiresisrecommendedinsteadof
24
