RemovingtheMowerDeck
Beforeservicingorremovingthemowerdeck,the
springloadeddeckarmsmustbelockedout.
WARNING
Deckliftarmassemblieshavestoredenergy.
Removingthedeckwithoutreleasingthestored
energycancauseseriousinjuryordeath.
DoNotattempttodisassemblethedeckfromthe
frontframewithoutlockingoutthestoredenergy.
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Removetheheightadjustmentpinandlowerthe
decktotheground.
3.Placetheheightadjustmentpininthe3inch(7.6cm)
cuttingheightlocation.Thislocksthedeckliftarms
inthelowestpositionwhenthedeckisremovedand
thestoredenergyinthedeckspringisreleased.
4.Removethebeltcovers.
5.Liftuptheoorpanandinsertaratchetintothe
squareholeinthedeckidler(
Figure97).
6.Rotatethedeckidlerclockwiseandremovethe
mowerbelt(Figure97).
Figure97
1.Clutchpulley5.Squareholeintheidler
armfortheratchet
2.Mowerbelt6.Idlergreasezerk
3.Springloadedidlerpulley
7.Beltguide
4.Ratchet
7.Removeandretainthehardwareonbothsidesofthe
deckasshowninFigure98.
60
