27
Operating manual Cruise 2.0
* The effective power available for boat propulsion (measured after deducting all deficits including
propeller deficits. Definition of propulsion output = thrust power x speed)
12. Trouble shooting 13. Technical data
• Repairs may only be carried out by authorized Torqeedo Service Centers.
Should you attempt to carry out repairs or conversions yourself, this
immediately cancels the warranty.
• In case of a warranty claim, please follow the warranty instructions at
the beginning of the instruction manual.
13. Technical data
Cruise 2.0 S Cruise 2.0 L
Input power in watts 2,000 2,000
Rated power in volts 24.0 24.0
Propulsive power in watts* 900 900
Maximum overall efficiency in % 45% 45%
Static thrust in lbf 121 121
Total weight in lbs 40 42
Maximum shaft length in inches 24.6 29.3
Integrated battery no no
Propeller dimensions in inches 12 x 10 12 x 10
Propeller speed at full power in rpm max. 920 max. 920
Control T
iller control / remote throttle
control
Tiller control / remote throttle
control
Steering 3
60° lockable 3
60° lockable
Tilting system gas pressure spring gas pressure spring
Trim system manual 5-step manual 5-step
Stepless drive forwards/reverse yes yes
