Torqeedo Deep Blue User Manual

Technical data
DE EN
page 13 / 117
3 Technical data
Model DEEP BLUE 80
- 1400/1800
DEEP BLUE 40
- 1400/1800
Maximum shaft power 62.8 kW/57.8 kW 25 kW
Continuous shaft power 50 kW 25 kW
Propulsive power > 32.4 kW > 16.2 kW
Equivalent motor power* 80 HP 40 HP
Weight of motor, including power
electronics (excluding batteries)
88 kg 88 kg
* The propulsive power of our electrical drives is comparable with
gasoline motors of this horse power
Protection class as per DIN EN 60529
Component Protection class
Charger unit IP67*
System Management Unit IP66**
Motor IP67
High-voltage battery IP67
Display and accelerator lever IP67
* dust-protected, protected against temporary submersion
** dust-protected, protected against strong water jet
Weight of DEEP BLUE system components
Weight
30.5 kWh BMW i3 high-voltage bat-
tery, with cooling and mounting frame
285 kg
Per 3 kW charger unit 10 kg
Per System Management Unit 18 kg
High-voltage battery 30.5 kWh BMW i3
Specification Value/unit
Rated voltage 345 V
Maximum voltage 396 V
Maximum continuous output power 55 kW
Nominal capacity 94 Ah
Dimensions with cooling 1958 mm x 1038 mm x 183.5 mm
Multiple batteries per motor Yes
Usable energy 30.5 kWh
Temperature range for storage -40 °C to +40 °C
Charge state during storage Between 30 % and 80 %
