1800 Series User Manual
28
OPTION CARD SLOT
The option card slot is a standard feature. An optional network adapter
card such as RemoteEye
®
II slides into the slot located on the back of the
electronics module (Figure, page 15). This optional interface allows the UPS
to be monitored across the network or from any point on the Internet.
The RemoteEye
®
II is an optional network card that allows the UPS to be
managed remotely using the common SNMP/web network protocols. For
more information contact Toshiba’s UPS Marketing Department at (800) 231-
1412 or by e-mail at toshibaups@tic.toshiba.com.
TROUBLESHOOTING
Warnings and Faults are those abnormal conditions that can occur and could
cause the unit to stop normal operation. These conditions are detected by
the protective circuitry in the unit. The UPS “Warning/Fault” lamp will light red
when a warning or fault occurs.
“Troubleshooting” involves monitoring the LED’s on the front panel and then
interpreting the readout by using the warning and fault mode display charts
that follow. Only the state of the LED’s listed in the chart should be considered.
Other LED’s might be active; nevertheless, only those listed under the column
“LED state” should be considered when diagnosing a warning, or fault.
WARNING/FAULT MODES
All warnings will cause the red “Warning/Fault” LED to ash. All faults will
cause the red “Warning/Fault” LED to light continuously.
Some warnings and most faults will cause the UPS to transfer to bypass mode.
In many cases, after the condition that caused the fault is corrected the unit
will automatically transfer back to normal mode. For those cases where the
unit does not transfer back automatically contact your Toshiba UPS service
representative at 1-877-867-8773 (outside the U.S. call 713-466-0277).
