ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R402 AE006221 R638U2680J R,FUSE 68 OHM 1/2W

! R410 AD301344 R3X18A151J R,METAL OXIDE 150 OHM 2W

! R416 AD301593 R002T23R3J RC 3.3 OHM 1/2W

! R420 AD301345 R002T22R7J RC 2.7 OHM 1/2W

! R426 BZ210030 R4X5T4472F R,METAL 4.7K OHM 1/4W

R434 AD301972 R5X2CF5R6J R,CEMENT 5.6 OHM 10W

! R436 BZ210023 R4X5T4183F R,METAL 18K OHM 1/4W

! R438 AE006222 R655812R7J R,FUSE 2.7 OHM 1W

! R439 BZ210003 R3K181102J R,METAL OXIDE 1K OHM 1W

! R441 BZ210231 R4X5T6153F R,METAL 15K OHM 1/6W

! R452 BZ210279 R3X181181J R,METAL OXIDE 180 OHM 1W

! R500 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W

! R501 AD301596 R5X2AE010J R,CEMENT 1 OHM 7W

! R502 BZ210249 R3X28A331J R,METAL OXIDE 330 OHM 2W

! R506 BZ210162 R002T4682J RC 6.8K OHM 1/4W

! R518 AD301973 R3X28BR22J R,METAL OXIDE 0.22 OHM 3W

! R520 BZ210206 R002T2155J RC 1.5M OHM 1/2W

! R527 BZ210149 R3X18AR68J R,METAL OXIDE 0.68 OHM 2W

! R541 AE005735 R63881R22J R,FUSE 0.22 OHM 1W

! R542 BZ210248 R3X181R15J R,METAL OXIDE 0.15 OHM 1W

! R602 AD301975 R3X28B120J R,METAL OXIDE 12 OHM 3W

! R649 BZ210215 R3X28B100J R,METAL OXIDE 10 OHM 3W

! R803 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

! R805 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

! R807 BZ210026 R3X18A153J R,METAL OXIDE 15K OHM 2W

CAPACITORS

! C408 BZ110032 E5EZF3102M CE 1000 UF 25V

! C413 AD301977 E0ELF4102M CE 1000 UF 35V

C418 BZ110136 P4J7F3394J CMPP 0.39 UF 250V PMS

! C420 BZ110058 P4N8FJ123H CMPP 0.012 UF 1.25KV

C425 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C426 BZ110225 E5EZFD220M CE 22 UF 250V

! C430 BZ110195 E02LU8220M CE 22 UF 100V

! C501 BZ210176 E02LF3222M CE 2200 UF 25V

! C502 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C503 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C504 AD301729 E02LU52R2M CE 2.2 UF 50V

! C505 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL

! C506 BZ110035 P2122B104M CMP 0.1 UF 275V ECQUL

! C507 BZ110012 E51CGC471M CE 470 UF 200V

! C508 BZ110222 CD39E0MH3M CC 0.0022UF 250V

! C513 AE000950 CD39E0ME3M CC 0.0015UF 250V

! C514 BZ210176 E02LF3222M CE 2200 UF 25V

C517 AE000874 C0PLRR7E3K CC 0.0015 UF 2KV R

! C519 AE000950 CD39E0ME3M CC 0.0015UF 250V

! C521 AE006083 E61DFB221M CE 220 UF 160V

! C527 BZ110119 E02LF2222M CE 2200 UF 16V

C535 BZ110201 C0PLRR7H3K CC 0.0022 UF 2KV R

C802 BZ110226 C0JBB07H3K CC 0.0022UF 2KV B

DIODES

D001 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

D104 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D105 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D106 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

D109 BZ410054 0021721150 LED SLR-342VCT32

D402 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D403 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77

D404 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

! D405 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D406 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

! D407 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D410 BZ410019 D97U03001B DIODE,ZENER MTZJ30B T-77

! D411 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D414 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D415 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

! D501 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D502 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D503 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D504 BZ410062 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D505 AE006082 D28F0PRA60 DIODE,RECTIFIER 30PRA60-FC

! D506 AD300731 D2WXN49370 DIODE,SILICON 1N4937

J2-1 20AF45
