SPECIFIC INFORMATIONS
CHASSIS AND CABINET REPLACEMENT PARTS LIST
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRE-
CAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Model: 21CZ3R/21CZ5R
Capacitors .......... CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............ CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Location Parts No. Description
No.
#1: [21CZ3R]
#2: [21CZ5R]
CAPACITORS
C101 76763101 ELECTROLYTIC 16V 100UF M
C102 76763221 ELECTROLYTIC 16V 220UF M
C103 76109103 CERAMIC CHIP 50V B 0.01UF K
C104 76105470 CERAMIC CHIP 50V CH 47PF J
C105 76105220 CERAMIC CHIP 50V CH 22PF J
C106 76796479 ELECTROLYTIC 35V 4.7UF M
C107 76105220 CERAMIC CHIP 50V CH 22PF J
C108 76503049 PLASTIC FILM 63V 0.47UF J
C109 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C110 76109103 CERAMIC CHIP 50V B 0.01UF K
C113 76109102 CERAMIC CHIP 50V B 1000PF K
C114 76109102 CERAMIC CHIP 50V B 1000PF K
C116 76109103 CERAMIC CHIP 50V B 0.01UF K
C118 76109102 CERAMIC CHIP 50V B 1000PF K
C120 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C121 76109103 CERAMIC CHIP 50V B 0.01UF K
C123 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C129 76109102 CERAMIC CHIP 50V B 1000PF K
C130 76797479 ELECTROLYTIC 50V 4.7UF M
C131 76814103 CERAMIC CHIP 50V F 0.01UF Z
C132 76100104 CERAMIC CHIP 25V F 0.1UF Z
C133 76105101 CERAMIC CHIP 50V CH 100PF J
C135 76109222 CERAMIC CHIP 50V B 2200PF K
C136 76206228 ELECTROLYTIC 50V 0.22UF M 7L 3A
C137 76100103 CERAMIC CHIP 50V F 0.01UF Z
C141 76105101 CERAMIC CHIP 50V CH 100PF J
C150 76814103 CERAMIC CHIP 50V F 0.01UF Z
C166 76109103 CERAMIC CHIP 50V B 0.01UF K
C167 76794101 ELECTROLYTIC 16V 100UF M
C170 76109103 CERAMIC CHIP 50V B 0.01UF K
C171 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C172 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C173 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C174 76105330 CERAMIC CHIP 50V CH 33PF J
C175 76105330 CERAMIC CHIP 50V CH 33PF J
C176 76105330 CERAMIC CHIP 50V CH 33PF J
C189 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
C192 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
C216 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C221 76105330 CERAMIC CHIP 50V CH 33PF J
C222 76105330 CERAMIC CHIP 50V CH 33PF J
C223 76105330 CERAMIC CHIP 50V CH 33PF J
C224 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C226 76590104 CERAMIC DISC 50V 0.1UF J
C227 76590104 CERAMIC DISC 50V 0.1UF J
C231 #2 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C232 #2 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C233 #2 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C234 #1 76109103 CERAMIC CHIP 50V B 0.01UF K
C235 #1 76109103 CERAMIC CHIP 50V B 0.01UF K
C236 76105120 CERAMIC CHIP 50V CH 12PF J
C237 76105120 CERAMIC CHIP 50V CH 12PF J
C304 76435330 CERAMIC DISC 500V SL 33PF J
C305 76617915 ELECTROLYTIC 50V 1UF K
C306 76794102 ELECTROLYTIC 16V 1000UF M
C307 76693473 PLASTIC FILM 100V 0.047UF J
C308 76765101 ELECTROLYTIC 35V 100UF M
C309 76797229 ELECTROLYTIC 50V 2.2UF M
C312 76796102 ELECTROLYTIC 35V 1000UF M
C313 76082280 PLASTIC FILM 100V 0.22UF J
C314 76212272 CERAMIC DISC 50V B 2700PF K
C315 76503049 PLASTIC FILM 63V 0.47UF J
C317 76214471 CERAMIC DISC 500V B 470PF K
C320 76765101 ELECTROLYTIC 35V 100UF M
C322 #2 76100104 CERAMIC CHIP 25V F 0.1UF Z
C410 76693472 PLASTIC FILM 100V 4700PF J
C417 76214102 CERAMIC DISC 500V B 1000PF K
C420 76794220 ELECTROLYTIC 16V 22UF M
C421 76794470 ELECTROLYTIC 16V 47UF M
C431 76797479 ELECTROLYTIC 50V 4.7UF M
C432 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C433 76100103 CERAMIC CHIP 50V F 0.01UF Z
C434 76100103 CERAMIC CHIP 50V F 0.01UF Z
C435 76794102 ELECTROLYTIC 16V 1000UF M
C436 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
C437 76109822 CERAMIC CHIP 50V B 8200PF K
C440 76503211 PLASTIC FILM 1500VH 1200PF H
C442 76082994 PLASTIC FILM 250V 0.3UF J
C444 76503278 PLASTIC FILM 1500VH 8700PF H
C445 76693104 PLASTIC FILM 100V 0.1UF J
C446 76700100 ELECTROLYTIC 250V 10UF M
C448 76073118 ELECTROLYTIC 160V 33UF M
C449 76763471 ELECTROLYTIC 16V 470UF M
C463 76109152 CERAMIC CHIP 50V B 1500PF K
C467 76828563 PLASTIC FILM 200V 0.056UF J
C470 76797220 ELECTROLYTIC 50V 22UF M
C472 76503049 PLASTIC FILM 63V 0.47UF J
C473 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C479 76105271 CERAMIC CHIP 50V CH 270PF J
C484 76590104 CERAMIC DISC 50V 0.1UF J
C485 76590104 CERAMIC DISC 50V 0.1UF J
C498 76590103 PLASTIC FILM 50V 0.01UF J
C502 76590103 PLASTIC FILM 50V 0.01UF J
C517 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
Location Parts No. Description
No.
To Next Page
