Service Mode
Key Function in the Service Mode
The following key entry during display of adjustment menu provides special functions.
ADJUSTMENT
CAUTION: Never try to perform initialization unless you have replaced the Main PC
Board.
Test signal selection
button (on remote control)
Selection of the adjustment items
P (on remote control)
Change of the data value
Volume +/− (on remote control)
Adjustment menu mode ON/OFF MENU button (on TV)
Initialization of the memory
"i+" + P button on TV
"RCUT" selection 1 button
"GCUT" selection 2 button
"BCUT" selection 3 button
"CNTX1" selection 4 button
"COLC2" selection 5 button
"UVTT2" selection 6 button
Automatic A/D Adjustment
(PC, Component, Composite (PAL, NTSC))
7 button
Self diagnostic display ON/OFF 9 button
TOSHIBA WEB-ZEUS
>> terms and conditions >> privacy policy
Copyright © 1995-2011 TOSHIBA Corporation, All Rights Reserved.

Toshiba 32PB1V1 Specifications

General

Screen Size	32 inches
Aspect Ratio	16:9
Refresh Rate	50 Hz
HDMI Ports	2
USB Ports	1
Resolution	1366 x 768 pixels
Display Type	LCD
Power Consumption	45 W
