Toshiba DVR80KF Service Manual

1-18-3 E9TK2PIN
IC612 ( VFD DRIVER )
Pin
No.
IN/
OUT
Signal
Name
Function
1OUT
POWER-
LED
POWER-LED Control Signal
2 OUT DVD-LED DVD-LED Control Signal
3 OUT VCR-LED VCR-LED Control Signal
4 - NU Not Used
5 IN OSC Oscillator Input
6 - NU Not Used
7 IN DRV-DIN Serial Data Input
8 IN DRV-CLK Serial Clock Input
9 IN DRV-STB Serial Interface Input
10 - NU Not Used
11 - NU Not Used
12 - VSS Ground
13 - VDD Power Supply
14 - NU Not Used
15 - NU Not Used
16 - NU Not Used
17 - NU Not Used
18 - NU Not Used
19 - NU Not Used
20 OUT P1
Segment Output
Serial Data Input
21 OUT P8
22 OUT P9
23 OUT P2
24 OUT P3
25 OUT P4
26 OUT P7
27 OUT P6
28 OUT P5
29 - NU Not Used
30 - VEE Pull Down Level
31 - NU Not Used
32 - NU Not Used
33 - NU Not Used
34 - NU Not Used
35 - NU Not Used
36
OUT
7G
Grid Output
37 6G
38 5G
39 4G
40 3G
41 2G
42 1G
43 - VDD Power Supply
44 - VSS
Ground
Pin
No.
IN/
OUT
Signal
Name
Function
