ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R401 AD302023 R3X28A181J R,METAL 180 OHM 2W

! R402 BZ210262 R3X28A221J R,METAL OXIDE 220 OHM 2W

! R408 BZ210285 R3X28AR47J R,METAL OXIDE 0.47 OHM 2W

! R418 BZ210130 R002T21R5J RC 1.5 OHM 1/2W

! R426 BZ210003 R3K181102J R,METAL OXIDE 1K OHM 1W

! R444 BZ210244 R4X5T6562F R,METAL 5.6K OHM 1/6W

! R445 AD301011 R4X5T6393F R,METAL 39K OHM 1/6W

! R447 AE006221 R638U2680J R,FUSE 68 OHM 1/2W

! R450 AE006460 R638812R2J R,FUSE 2.2 OHM 1W

! R803 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R805 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R807 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

R3025 BZ210204 R3X1814R7J R,METAL OXIDE 4.7 OHM 1W

! R3800 BZ210230 R4X5T6332F R,METAL 3.3K OHM 1/6W

! R3803 BZ210206 R002T2155J RC 1.5M OHM 1/2W

! R3806 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W

! R3812 BZ210217 R3X181331J R,METAL OXIDE 330 OHM 1W

! R3817 BZ210117 R5X2CE010J R,CEMENT 1 OHM 7W

! R3821 BZ210063 R3X181R22J R,METAL OXIDE 0.22 OHM 1W

! R3828 AE005735 R63881R22J R,FUSE 0.22 OHM 1W

! R3829 AD301203 R002T4101J RC 100 OHM 1/4W

CAPACITORS

! C357 AD300067 E02LF4102M CE 1000 UF 35V

! C402 AD300064 E02LT8220M CE 22 UF 100V

! C407 BZ210176 E02LF3222M CE 2200 UF 25V

! C421 BZ110065 E5EZT4471M CE 470 UF 35V

C423 BZ110136 P4J7F3394J CMPP 0.39 UF 250V PMS

! C428 AD301978 P4N8FJ133H CMPP 0.013 UF 1.25KV

! C431 BZ110204 E0ELFD220M CE 22 UF 250V

C450 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

C802 BZ110226 C0JBB07H3K CC 0.0022UF 2KV B

C1525 BZ110254 CQG0B0415K CC 0.1 UF 50V B

! C3801 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL

! C3810 AE001347 C0J0B05H3K CC 0.0022UF 500V B

C3811 BZ110203 C0PLRR7W2K CC 820 PF 2KV RR

! C3812 AE001347 C0J0B05H3K CC 0.0022UF 500V B

! C3815 BZ110012 E51CGC471M CE 470 UF 200V

! C3816 AE002878 CD39E0MQ3M CC 0.0047UF 250V

! C3818 BZ110169 E5EZF2332M CE 3300 UF 16V

! C3820 AD301348 E02LU5100M CE 10 UF 50V

! C3822 BZ110028 E5EZT2102M CE 1000 UF 16V

! C3823 BZ110032 E5EZF3102M CE 1000 UF 25V

C3824 BZ110239 C03L0R7L2K CC 330 PF 2KV R

! C3826 AE004799 E61SFC221M CE 220 UF 200V

! C3827 BZ110101 E5EZF3222M CE 2200 UF 25V

DIODES

D101 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D102 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D105 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D106 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D301 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D401 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

! D402 AD300731 D2WXN49370 DIODE,SILICON 1N4937

D403 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

D404 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

D405 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D406 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D408 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

! D409 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D410 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77

! D411 AD300731 D2WXN49370 DIODE,SILICON 1N4937

! D413 AD300731 D2WXN49370 DIODE,SILICON 1N4937

D414 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

! D416 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

D603 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

D604 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D605 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D606 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D607 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D609 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D801 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

J3-1
