Chapter 9: Appendix
Specifications
Note:
• This model complies with the specifications listed
below.
• Designs and specifications are subject to change
without notice.
• This model may not be compatible with features and/or
specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear,
unencrypted)
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source: 120 V AC, 60 Hz
Power Consumption
32HL37/32HL37U/32HL17/32HL17U:
101 W (average)
0.5 W in standby mode
37HL17: 116 W (average)
0.5 W in standby mode
42HL17: 161 W (average)
0.6 W in standby mode
Audio Power
10 W + 10 W
Speaker Type
Two 2-3/8 × 4-3/4 inches (6 × 12 cm)
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 22 k
ohm or greater)
ColorStream
®
(component video) HD INPUT:
VIDEO:Y: 1V(p-p), 75 ohm
P
R: 0.7 V(p-p), 75 ohm
P
B: 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 720p, 480p, 480i
AUDIO: 150 mV(rms), 22 k ohm or greater
HDMI™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
Audio Lip Sync supported
Suggested formats: See table below.
HDMI Audio: 2-channel Linear-PCM; 32/44.1/48 kHz
sampling frequency; 16/20/24 bits per sample
FIXED AUDIO OUTPUT:
150 mv (rms) (30% modulation equivalent, 2.2 k ohm
or less)
DIGITAL AUDIO OUTPUT:
Optical type
PC INPUT:
15-Pin D-sub Analog RGB
Dimensions
32HL37/32HL37U/32HL17/32HL17U:
Width: 31-1/2 inches (800 mm)
Height: 23-3/8 inches (592 mm)
Depth: 11-1/4 inches (285 mm)
37HL17: Width: 36-1/4 inches (920 mm)
Height: 26-1/8 inches (661 mm)
Depth: 11-1/4 inches (285 mm)
42HL17: Width: 40-1/2 inches (1,027mm)
Height: 28-5/8 inches (724 mm)
Depth: 13-1/4 inches (335 mm)
Mass (weight)
32HL37/32HL37U/32HL17/32HL17U:
38.6 lbs (17.5 kg)
37HL17: 46.3 lbs (21.0 kg)
42HL17: 59.5 lbs (27.0 kg)
Operating conditions
Temperature: 32ºF - 95ºF (0ºC - 35ºC)
Humidity: 20 - 80% (no moisture condensation)
Supplied Accessories
• Remote control with two size “AAA” batteries
• Owner’s manual (this book)
• Lead clip
Use this clip to attach the TV to a wall, pillar, or other
immovable structure. See item 20 on page 3.
HDMI input supports the following signal formats:
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency
VGA 640 x 480p 59.940/60Hz 31.469/31.500kHz 25.175/25.200MHz
480i 720 x 480i 59.940/60Hz 15.734/15.750kHz 27.000/27.027MHz
480p 720 x 480p 59.940/60Hz 31.469/31.500kHz 27.000/27.027MHz
720p 720 x 480p 59.940/60Hz 44.955/45.000kHz 74.176/74.250MHz
1080i 1920 × 1080i 59.940/60Hs 33.716/33.750kHz 74.176/74.250MHz
1080p 1920 × 1080p 23.976/24Hz 26.973/27.000kHz 74.176/74.250MHz
1080p 1920 × 1080p 59.940/60Hz 67.433/67.500kHz 148.352/148.500MHz
