5.1.7. Object 6046: vl_velocity_min_max_amount
This object indicates the configured minimum and maximum amount of velocity (unit min
-1
). The
vl_velocity_max amount sub-object is mapped internally to the vl_velocity_max positive and vl_velocity_max
negative values. The vl_velocity_min amount sub-object is mapped internally to the vl_velocity_min positive
and vl_velocity_min negative values.
At initial configuration, the Upper limit frequency (ul) and Lower limit frequency (ll) of the drive may be
not same value with Object 6046 setting value. And when change the Upper limit frequency and the lower
limit frequency of the drive parameter, Object 6046 value is different with the drive parameters. To
correspond these limit value, set Object 6046. And if need, execute Store Parameters command (Object
1010) to save the parameter to EEPROM.
5.1.8. Object 6048h: vl_velocity_acceleration
This object indicates the configured delta speed and delta time of the slope of the acceleration ramp. Unit is
min
-1
.
Velocity Acceleration Delta Speed : 225 ~ 30,000 min-1
Velocity Acceleration Delta Time : 0 ~ 3600 s
Note: Do not change the acceleration/deceleration time unit (parameter f519), if change the parameter,
the setting value range will be different from above range.
5.1.9. Object 6049: vl_velocity_deceleration
This object shall indicate the configured delta speed and delta time of the slope of the deceleration ramp.
Unit is min
-1
.
Velocity Deceleration Delta Speed : 225 ~ 30,000 min-1
Velocity Deceleration Delta Time : 0 ~ 3600 s
Note: Do not change the acceleration/deceleration time unit (parameter f519), if change the parameter,
the setting value range will be different from above range.
5.1.10. Object 604A: vl_velocity_quick_stop
This object indicates the configured delta speed and delta time of the slope of the deceleration ramp for
quick stop. Unit is min
-1
.
5.1.11. Object 605A: Quick stop option code
This object shall indicate what action is performed when the quick stop function is executed.
The slow down ramp is the deceleration value of the used mode of operations.
Value Definition
-32768 to -1 No function
0 Disable drive function
+1 Slow down on slow down ramp and transit into Switch On Disabled
+2 Slow down on quick stop ramp and transit into Switch On Disabled
+3 Do not set
+4 Slow down on voltage limit and transit into Switch On Disabled
+5 Slow down on slow down ramp and stay in Quick Stop Active
+6 Slow down on quick stop ramp and stay in Quick Stop Active
+7 Do not set
+8 Slow down on voltage limit and stay in Quick Stop Active
+9 to +32 767 Reserved
