2. Overview
This product is a dual port PROFINET communication module that can be used in a PROFINET Industrial
Ethernet. This product also offers an embedded Web server which offers comfortable monitoring and
setup directly from a standard web browser.
2.1. Specification
Module specifications
Item Specification
Type-form PNE001Z
Applicable inverter
VF-S15 CPU1 Ver.112 or later (With SBP009Z)
VF-AS3
VF-MB1 CPU1 Ver.116 or later
Connector Dual RJ45 shielded connector
Supported network PROFINET, Modbus TCP
Indicator
4 LEDs indicating the communication status and error
status.
Protection degree IP20
Environments
Correspond to inverter.
Note) The maximum ambient temperature for VF-AS3 is 50
de
g
rees when the option is installed.
Network specifications
Item Specification
PROFINET
Baud rate 100Mbps (Full duplex)
Cyclic communication
PROFIdrive V.4.1 (Telegram1)
4PKW and 2 PZD vendor format (Telegram100)
4PKW and 6 PZD vendor format (Telegram101)
6 PZD vendor format (Telegram102)
Acyclic communication
Reading the PROFIdrive parameter
Reading/writing the inverter parameters
Configuration Configure by PROFINET master
IP configuration mode Manual setup, DCP, DHCP, Embedded Web server
PROFINET IO classes Conformance Class-B
I&M I&M function 0
Response time
*Cyclic communication About 11ms on VF-AS3
Cyclic communication About 14ms on VF-S15/MB1
Modbus TCP
Baud rate 10/100Mbps (Full/Half duplex)
Supported function
Read Holding Registers (03H)
Write Single Register (06H)
Write Multiple Registers (10H)
Read Device Identification (2BH)
IP configuration mode Manual setup, DHCP, Embedded Web server
Ethernet
MRP Supported
LLDP Supported
Web server
Inverter status monitor, inverter parameter
monitor/configuration, Network status monitor,
password lock
*Response time is the time until the inverter is operated by RUN command on the cyclic communication
