Toshiba Tosvert VF-S15 Function Manual

E6582051
- 52 -
6.7.
PROFIdrive parameter (PNU)
PNU R/W data type Note
915 R Array [6]
Unsigned16
PNU 915, IND 0 = the inverter parameter c001
PNU 915, IND 1 = the inverter parameter c002
PNU 915, IND 2 = the inverter parameter c003
PNU 915, IND 3 = the inverter parameter c004
PNU 915, IND 4 = the inverter parameter c005
PNU 915, IND 5 = the inverter parameter c006
916 R Array [6]
Unsigned16
PNU 916, IND 0 = the inverter parameter c021
PNU 916, IND 1 = the inverter parameter c022
PNU 916, IND 2 = the inverter parameter c023
PNU 916, IND 3 = the inverter parameter c024
PNU 916, IND 4 = the inverter parameter c025
PNU 916, IND 5 = the inverter parameter c026
922 R Unsigned16 Telegram selection ( same as the inverter parameter c152)
1, 100, 101, 102
923 R Array [156]
Unsigned16
List of all the parameters for signals
930 R Unsigned16 Operating mode
1: supports the speed control mode and the speed setpoint
channel comprises RFG functionality.
944 R Unsigned16 Fault message counter
947 R Array [1]
Unsigned16
Currently failure code
964 R
Array [5]
Unsigned16
Inverter Unit identification
IND 0 = Manufacturer-ID
PNE001Z :
0x190
PNE001Z-1,-2: 0x031A
IND 1 = Model number
IND 2 = Inverter CPU1 version
IND 3 = Inverter firmware release year (yyyy)
IND 4 = Inverter firmware release date (ddmm)
965 R Array [1]
Octet String2
Profile number (PROFIdrive, V4.1)
