3
1. Determine the location
Make sure that the wall has sufficient structural strength.
At least 2 screws at each mounting flange must mount
into a wood stud. A stud sensor or another stud locating
method can be used to locate the studs behind the wall.
Place the grab bar on the wall where desired, making
sure that at least two mounting holes at each mounting
flange are positioned over a wood stud.
2. Drill holes
Determine the required location for grab bar installation.
For easy installation, a cut-out hole is provide at left end
side of each grab bar. Put a screw half way into the wall
to hang the left end of the grab bar and make all marking
locations on the wall accordingly. Use of a level is
recommend in making the marks Then, Drill 1/8” (3mm)
diameter holes at all marked screw locations.
Hole width
Plywood：1/8”(3mm)
3. Attach the product
Mount the grab bar using all the screws, #9 x 1-1/2” (d 4.5 x 45mm) provided. Tighten the screws until secure.
Care should be taken to avoid scratching the product finish during installation.
Remove the cover
Remove the cover
Guinevere Soiree
4. Insert the cover
Push the flanges onto the mountings securely.
5. Installation Complete
Cover Cover
Guinevere Soiree Guinevere Soiree
Cleaning Instructions
•For general cleaning
•For cleaning dirt
•Avoid using anything that may scratch the grab bar surface.
Never use polishing powder, detergent that includes coarse particles,
thinner, benzine, acid or alkaline detergent, or a nylon scrub brush.
They will damage the surface of the grab bar.
Caution
Use a damp, soft cloth to clean the grab bars.
Use a soft cloth with diluted dish washing detergent.
Wipe the area using a wet cloth and dry using a soft cloth.
Use soft cloth for maintenance
