2004 CELICA (EWD538U)
109
ILLUMINATED ENTRY SYSTEM
∗ Lights ON condition
When any door (Driver’s side, front passenger’s side, or back door etc.) is opened.
∗ Lights OFF condition
If any of the following conditions are met while the dome light is ON, the light fades out and is turned OFF.
When approximately 15 seconds have elapsed after all doors are closed.
When all doors are closed and the driver’s side door and the front passenger’s side door is locked.
When all the doors are closed with the ignition SW at ACC or ON position.
D3, D4 DOOR COURTESY SW LH, RH
1-GROUND : Closed with door open
L4 LUGGAGE ROOM LIGHT SW
1-GROUND : Luggage compartment door open
: PARTS LOCATION
Code See Page Code See Page Code See Page
B6 A 36 D6 38 J12 A 38
B7 B 36 E2 A 32 (1ZZ-FE) J13 B 38
C12 A 36 E3 B 32 (1ZZ-FE) L3 38
C13 B 36 E8 E 34 (2ZZ-GE) L4 38
D3 38 J3 37 M3 A 39
D4 38 J10 37 P6 B 39
D5 38 J11 38
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
II
IK
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IM
IN 25 Floor Wire and Instrument Panel J/B (Instrument Panel Brace RH)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IA2
44 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IB1 44 Roof Wire and Instrument Panel Wire (Left Kick Panel)
IE5 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IH1
Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IH2
46 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BA1 48 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
BB1 48 Back Door No.2 Wire and Back Door No.1 Wire (Back Door Upper Left)
: GROUND POINTS
Code See Page Ground Points Location
IE 44 Cowl Side Panel LH
IF 44 Instrument Panel Brace RH
IH 44 Cowl Side Panel RH
SYSTEM OUTLINE
SERVICE HINTS
To Next Page
