2004 CELICA (EWD538U)
115
T2 TURN SIGNAL FLASHER RELAY
3-GROUND : Approx. 12 volts with the ignition SW on or the hazard SW on
1-GROUND : Changes from 12 to 0 volts with the ignition SW on and the turn signal SW LH or RH position,
and with the hazard SW on
2-GROUND : Always continuity
: PARTS LOCATION
Code See Page Code See Page Code See Page
C12 A 36
F10
32 (1ZZ-FE) J5 B 37
C13 B 36
F10
34 (2ZZ-GE) J7 37
C15 36 H7 37 R6 39
F9
32 (1ZZ-FE) J3 37 R7 39
F9
34 (2ZZ-GE) J4 A 37 T2 37
,,,
,,
,
,,,
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IC 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IE
II
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IM
()
IO 25 Floor Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2F 23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IE4 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
: GROUND POINTS
Code See Page Ground Points Location
EA
40 (1ZZ-FE)
Front Right Fender
EA
42 (2ZZ-GE)
Front Right Fender
EB
40 (1ZZ-FE)
Front Left Fender
EB
42 (2ZZ-GE)
Front Left Fender
IE 44 Cowl Side Panel LH
IF 44 Instrument Panel Brace RH
IG 44 Cowl Side Panel RH
BL 48 Back Panel Center
SERVICE HINTS
