: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
II 25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IN
IO
25 Floor Wire and Instrument Panel J/B (Instrument Panel Brace RH)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA2 44 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE5 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IF1 46 Floor Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IH2 46 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
: GROUND POINTS
Code See Page Ground Points Location
IE 44 Cowl Side Panel LH
IF 44 Instrument Panel Brace RH
