2004 CELICA (EWD538U)
185
C9 CIGARETTE LIGHTER
2-GROUND : Approx. 12 volts with the ignition SW at ACC or ON position
4-GROUND : Always continuity
C10 CLOCK
5-GROUND : Always 12 volts (Power for clock)
4-GROUND : Approx. 12 volts with the ignition SW at ACC or ON position (Power for indication)
1-GROUND : Always continuity
: PARTS LOCATION
Code See Page Code See Page Code See Page
C9 36 C13 36
C10 36 J6 37
,,,
,,
,
,,,
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IF
II
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IM
()
: GROUND POINTS
Code See Page Ground Points Location
IF 44 Instrument Panel Brace RH
