2004 CELICA (EWD538U)
203
R2 (A) RADIO AND PLAYER
(A) 4-GROUND : Always approx. 12 volts
(A) 3-GROUND : Approx. 12 volts with the ignition SW at ACC or ON position
(A) 7-GROUND : Always continuity
: PARTS LOCATION
Code See Page Code See Page Code See Page
A21 38 F15 38 R3 B 37
F13 38 F16 38 R8 39
F14 38 R2 A 37 R9 39
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
II 25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1 44 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IF1
Floor Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IF2
46 Floor Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IH1 46 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
: GROUND POINTS
Code See Page Ground Points Location
IF 44 Instrument Panel Brace RH
SERVICE HINTS
To Next Page
