2004 CELICA (EWD538U)
205
A21 AUTO ANTENNA CONTROL RELAY
1-GROUND : Always continuity
2-GROUND : Always approx. 12 volts
6-GROUND : Approx. 12 volts with the ignition SW at ACC or ON position
5-GROUND : Approx. 12 volts with the ignition SW at ON or ST position
: PARTS LOCATION
Code See Page Code See Page Code See Page
A21 38 J14 38 R4 B 37
J8 37 R2 A 37
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
II
Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
IK
25 Instrument Panel Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2D 23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IE4 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IF1
Floor Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IF2
46 Floor Wire and Instrument Panel Wire (Instrument Panel Brace LH)
: GROUND POINTS
Code See Page Ground Points Location
BJ 48 Luggage Room Left
SERVICE HINTS
To Next Page
