2004 CELICA (EWD538U)
213
Fan motor operation
The fan motor is operated according to the condition of the A/C operation, water temperature, or abnormality in the A/C
system.
A3 A/C SINGLE PRESSURE SW
3-2 : Open above approx. 15.5 kgf/cm
2
(220 psi, 1520 kpa)
Close below approx. 12.5 kgf/cm
2
(178 psi, 1226 kpa)
: PARTS LOCATION
Code See Page Code See Page Code See Page
32 (1ZZ-FE) A3 34 (2ZZ-GE)
33 (1ZZ-FE)
A1
34 (2ZZ-GE) E3 B 32 (1ZZ-FE)
R1
35 (2ZZ-GE)
A3 32 (1ZZ-FE) E10 G 34 (2ZZ-GE)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
Code See Page Junction Block and Wire Harness (Connector Location)
IC 25 Engine Room Main Wire and Instrument Panel J/B (Instrument Panel Brace RH)
2F
2G
23 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
2H
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EA3 42 (2ZZ-GE) Engine Wire and Engine Room Main Wire (Inside of Engine Room R/B No.1)
IE4 44 Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Brace LH)
IG5 46 Engine Room No.2 Wire and Instrument Panel Wire (Right Kick Panel)
: GROUND POINTS
Code See Page Ground Points Location
EA
42 (2ZZ-GE)
Front Right Fender
40 (1ZZ-FE)
Front Left Fender
EM
42 (2ZZ-GE)
IG 44 Cowl Side Panel RH
SYSTEM OUTLINE
SERVICE HINTS
To Next Page
