1. How to read component figures
(1) The component figures use the illustration in the parts
catalog for the vehicle model. Please refer to the catalog
to check the part name.
2. Matters omitted from this manual
(1) This manual omits descriptions of the following jobs, but perform them in actual operation:
(a) Cleaning and washing of removed parts as required
(b) Visual inspection (partially described)
TERMINOLOGY
CAUTION:
Important matters, negligence of which may cause accidents. Be sure to observe them.
NOTE:
Important items, negligence of which may cause accidents, or matters in operating procedure
which require special attention.
Standard: Value showing the allowable range in inspection or adjustment
Limit: The maximum or minimum value allowed in inspection or adjustment.
ABBREVIATIONS
Abbreviation Meaning Abbreviation Meaning
ASSY Assembly SAE
Society of Automotive Engineers
(USA)
ATT Attachment SAS System of active stability
LH Left Hand SST Special Service Tool
L/ Less STD Standard
OPT Option T= Tightening Torque
O/S Oversize {{T Number of teeth ({{T)
PS system Power Steering U/S Undersize
RH Right Hand W/ With
(Example)
3201
Parts catalog
FIG number
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
