27
Chapter 6
Guest Network
6. 1. Create a Network for Guests
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to Advanced > Wireless > Guest Network or click Wireless on the top page. Locate
the Guest Network section.
3. Create a guest network as needed.
1 ) Tick the Enable checkbox for the 2.4GHz or 5GHz wireless network.
2 ) Customize the SSID. Don‘t select Hide SSID unless you want your guests to
manually input the SSID for guest network access.
3 ) Select the Security type.
If No security is selected, no password is needed to access your guest network.
If WAP/WPA2-Personal is selected, customize your own password.
4. Click Save. Now your guests can access your guest network using the SSID and
password you set!
5. You can also click Sharing Network to share the SSID and password to your guests.
Tips:
To view guest network information, go to Network Map and locate the Guest Network section. You can turn on or off the
guest network function conveniently.

Table of Contents

Other manuals for TP-Link Archer C64

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer C64 and is the answer not in the manual?

TP-Link Archer C64 Specifications

General IconGeneral
DSL WAN-
Ethernet WANYes
SIM card slotNo
Firewall securitySPI
Security algorithmsWPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Supported network protocolsIPv4, IPv6
Networking standardsIEEE 802.1x
Receiver sensitivity5 GHz: 11a 6Mbps:-95dBm 11a 54Mbps:-77dBm 11ac VHT20 MCS8:-71dBm 11ac VHT40 MCS9:-67dBm 11ac VHT80 MCS9:-63dBm 2.4 GHz: 11g 6Mbps: -96dBm 11g 54Mbps: -78dBm 11n HT20 MCS7:-77dBm 11n HT40 MCS7:-74dBm 11ac VHT20 MCS8:-73dBm 11ac VHT40 MCS9:-68dBm
Ethernet LAN interface typeGigabit Ethernet
CertificationCE, RoHS
Processor frequency1200 MHz
Windows operating systems supportedWindows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Product typeTabletop router
Product colorBlack
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Cables includedLAN (RJ-45)
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1200 Mbit/s
WLAN data transfer rate (first band)400 Mbit/s
WLAN data transfer rate (second band)867 Mbit/s
Transmit powerCE: \u003C20dBm(2.4 GHz), \u003C23dBm(5.15 GHz~5.25 GHz) FCC: \u003C30dBm(2.4 GHz & 5 GHz) dBmW
Antennas quantity4
Output current1 A
Output voltage12 V
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Width120 mm
Height27.9 mm
