HHiigghh AAllttiittuuddee IInnssttaallllaattiioonn
Input ratings (BTUH) of these furnaces are based on
sea level operation and should not be changed at
elevations up to 2000 ft. If the unit installation is from
2000 to 8000 feet elevation, then change the burner
orifices to the size listed in Table 12, p. 21. Refer to
Table 13, p. 21 for orifice part numbers.
Table 12. Orifice Twist Drill Size
Orifice Twist
Drill Size if
Installed at
Sea Level
Altitude Above Sea Level and Orifice Change Required for that Elevation
2000 3000 4000 5000 6000 7000 8000
32 33 34 35 35 36 36 37
33 35 35 36 36 37 38 38
37 38 39 39 40 41 42 42
49 50 50 50 51 51 51 52
52 52 53 53 53 53 53 54
From National Fuel Gas Code — Table F-4
Table 13. Orifice Part Numbers
Drill Size
Part
Number
Drill Size
Part
Number
32 ORF01307 41 ORF01413
33 ORF0134 42 ORF01410
34 ORF01335 49 ORF01333
35 ORF01407 50 ORF01332
36 ORF01408 51 ORF01336
37 ORF01406 52 ORF01331
38 ORF01306 53 ORF01411
39 ORF01409 54 ORF01412
40 ORF01336
Air Filter Installation
The packaged unit requires an air filter. The unit does
not come with a factory installed filter rack in it,
however, two filter frame accessories are offered that
will allow the installation of a filter within the unit,
BAYFLTR101 & BAYFLTR201. Otherwise a field
supplied filter rack must be installed by the installer in
the return duct work.
Affix the filter label supplied with the unit adjacent to
the filter area. Refer to Table 14, p. 21 to determine
filter size.
Table 14. Determine Filter Size
Unit
Nominal
CFM
Filter Size
(Sq Ft)
Filter
(a)
Resistance
(W.C.)
YC~4024A 800 2.67 0.08
YC~4030A 1000 3.33 0.08
YC~4036A 1200 4.00 0.08
YC~4042A 1400 4.67 0.08
YC~4048A 1600 5.33 0.08
YC~4060A 2000 6.67 0.08
(a)
Filters must be installed in the return air system. The above square
footages are based on 300 F.P.M. face velocity. If permanent filters
are used, size per mfg. Recommendation with clear resistance of
0.05" WC.
IImmppoorrttaanntt:: Air filters and media wheels or plates shall
meet the test requirements in UL 900.
UUnniitt IInnssttaallllaattiioonn
