18-EB40D1-1C-EN
5
Product Specifications
MODEL 4YCC4024*1 4YCC4030*1
4YCC4036*1070
[4YCC4036*1090]
RATED Volts/PH/Hz 208–230/1/60
Performance Cooling BTUH
(a)
23200 28000 36400
Indoor Airflow (CFM)
785 880 1215
Power Input (KW)
LOCATED ON UNIT NAMEPLATE
EER2/SEER2 BTU/Watt-Hr 11.00 / 13.40
Sound Power Rating [dB(A)]
(b)
66.6 70 69.3
PERFORMANCE HEATING
(c)
Input BTUH-1st Stage (Natural Gas)
(d)
LOCATED ON UNIT NAMEPLATE
AFUE 81
Temp. Rise -min/max (°F)
30/60 30/60
30/60 [35/65]
Orifice Qty/drill size (Nat Gas) 2 / #37 2 / #33 2 / #33 [3 / #37]
POWER CONN. — V/Ph/Hz 208–230/1/60
Min. Brch. Cir. Ampacity
(e)
LOCATED ON UNIT NAMEPLATE
Fuse Size — Max. (amps)
LOCATED ON UNIT NAMEPLATE
Fuse Size — Recmd. (amps)
LOCATED ON UNIT NAMEPLATE
COMPRESSOR SCROLL
VOLTS/PH/HZ 208–230/1/60
R.L. Amps — L.R. Amps
LOCATED ON UNIT NAMEPLATE
OUTDOOR COIL — TYPE SPINE FIN
Rows/F.P.I 2 / 24
Face Area (sq. ft.)
13.2 13.3 15.5
Tube Size (in.)
3/8
INDOOR COIL — TYPE MCHE
Rows/F.P.I 2/16 2/16 2/16
Face Area (sq. ft.)
2.7 2.7 2.7
Tube Size (in.)
0.81 0.81 1
Refrigeration Control
EXPANSION VALVE
Drain Conn. Size (in.)
3/4 FEMALE NPT
OUTDOOR FAN — TYPE
Swept
DIA. (IN.)
23.4
DRIVE/NO. SPEEDS DIRECT / 1
CFM @ 0.0 in. w.g.
(f)
2350 2800 3080
Motor — HP/R.P.M 1/12 / 810 1/6 / 825 1/5 /825
Volts/Ph/Hz 208–230/1/60
F.L. Amps/L.R Amps
LOCATED ON UNIT NAMEPLATE
INDOOR FAN — TYPE
Const. Torque ECM
Dia. x Width (in.)
10.62 x 10.62
Drive/No. Speeds
DIRECT / 4
CFM @ 0.0 in. w.g.
(g)
SEE FAN PERFORMANCE TABLE
Motor — HP / R.P.M. 1/3 / 1050 1/2 / 1050 3/4 / 1050
Volts/Ph/Hz 208–230/1/60
COMBUSTION FAN-TYPE
Centrifugal
Drive / no. Speeds
Direct 1
Motor- HP / R.P.M. 1/34 /3345 1/34 /3290 1/34 /3290
F.L. Amps
LOCATED ON UNIT NAMEPLATE
FILTER / FURNISHED
NO
Type Recommended
THROWAWAY
Recmd. Face Area (sq. ft)
(h)
4.0 4.0 4.0
REFRIGERANT R-410
Charge (lbs.)
LOCATED ON UNIT NAMEPLATE
Subcooling
10° 8° 11°
(a)
Rated in accordance with AHRI Standard 210/240. AHRI standard rating conditions are: 80 D.B.67 W.B. entering air to indoor coil. 95 D. B. entering air to
outdoor coil.
(b)
Sound Power values are not adjusted for AHRI 270–95 tonal corrections.
(c)
Ratings shown are for elevations up to 2000 ft. For higher elevations reduce ratings at a rate of 4% per 1000 ft. elevation.
(d)
Convertible to LPG.
(e)
This value is approximate. For more precise value, see Unit Nameplate.
(f)
Standard Air — Dry Coil — Outdoor.
(g)
Based on U.S. Government Standard Tests.
(h)
Filters must be installed in return air stream. Square footages listed are based on 300 f.p.m. face velocity. If permanent filters are used size per
manufacturer’s recommendation with a clean resistance of 0.05” W.C.
IInnttrroodduuccttiioonn,, UUnniitt IInnssppeeccttiioonn aanndd SSppeecciiffiiccaattiioonn
