Trane Cold Generator CGWR Series User Manual

6 CG-SVX038A-EN
Unit Components
Forklift Pockets
Optional Disconnect
Switch Location
Evaporator Water
Inlet (Vic)
Evaporator Water
Outlet (Vic)
Condenser Water
Outlet (FPT)
Condenser Water
Inlet (FPT)
Power Wiring
Location
Unit Nameplate
(inside door)
Optional 15.4” Color Touchscreen
(Keypad w/ Display comes standard)
Rigging Bracket
Install Pockets
Removable Water
Plate on Shell-and-
Tube Condenser
Suction Line
(1 per circuit)
TXV
(1 per circuit)
Charging Port
(1 per circuit)
Relief Valve
(1 per circuit)
Filter Drier
(1 per circuit)
Hot Gas Injection
Solenoid Valve
(1 per circuit)
Liquid Line
(1 per circuit)
Solenoid Valve
(1 per circuit)
Sight Glass
(1 per circuit)
Compressor
Nameplate

Trane Cold Generator CGWR Series Specifications

General

Brand	Trane
Model	Cold Generator CGWR Series
Category	Chiller
Language	English
