Trane CVHF User Manual

CVHE-SVX02M-EN
19
Weights (kg)
IImmppoorrttaanntt:: The weight information provided here
should be used for general information
only. Trane does not recommend using this
weight information for considerations
relative to chiller handling, rigging, or
placement. The large number of variances
between chiller selections drives variances
in chiller weights that are not recognized in
these tables. For specific weights for your
chiller, refer to your submittal package.
Table 4. Representative weights, 60 Hz chillers (kg)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHE
230–320
233
032S 032S
6726 6109 — —
289 — — 7488 6871
230–320 289 032S 032L 7000 6316 7762 7078
230–320 289 032L 032L 7383 6611 8145 7373
230–320 289 050S 050S 9088 7983 9850 8745
230–320 289 050S 050L 9526 8326 10288 9088
230–320 289 050L 050L 10139 8756 10901 9518
360–500 455 050S 050S 9397 8292 10159 9054
360–500 455 050S 050L 9835 8635 10597 9398
360–500 455 050L 050L 10448 9065 11210 9828
360–500 455 050S 080S 10523 9192 11285 9954
360–500 455 050L 080L 12153 10422 12915 11184
360–500 455 080S 080S 13542 11627 14304 12389
360–500 455 080S 080L 14262 12209 15024 12971
360–500 455 080L 080L 15179 12852 15941 13614
CVHF
350–570 588 050S 050S 9293 8157 10055 8919
350–570 588 050S 050L 9731 8501 10493 9263
350–570 588 050L 050L 10298 8875 11060 9637
350–570 588 050S 080S 10419 9057 11181 9819
350–570 588 050L 080L 12026 10232 12788 10994
350–570 588 080S 080S 14445 12246 14593 12571
350–570 588 080S 080L 14574 12391 15336 13153
350–570 588 080L 080L 15567 13088 16329 13850
350–910 957 080S 080S 14897 12875 16258 14236
350–910 957 080S 080L 15640 13457 17001 14818
350–910 957 080L 080L 16633 14154 17994 15515
350–910 957 080L 142L 20327 17084 21688 18444
350–910 957 142M 142L 21975 18389 23336 19749
350–910 957 142L 142L 22529 18803 23889 20164
1070–1300 1062 080L 142L 20734 17490 22094 18851
1070–1300 1062 142M 142L 22279 18693 23639 20053
1070–1300 1062 142L 142L 22832 19107 24193 20467
1070–1300 1062 142E 142L 23479 19554 24840 20915
1070–1300 1062 142M 210L 24976 20891 26336 22252
1070–1300 1062 142L 210L 25552 21305 26913 22666
1070–1300 1062 142E 210L 26199 21752 27559 23113
1070–1300 1062 210L 210L 28077 23555 29438 24915
UUnniitt CClleeaarraanncceess aanndd WWeeiigghhttss
