Trane DELUXE programable XT302C User Manual

50
Pub. No. 22-5127-04
69-1214
The preprogrammed schedule is as follows (same schedule for all days of the week): You may keep this
schedule or organize your own.
Table 4. 24-Hour Preprogrammed Schedule.
Customizing Your Own 24-Hour Schedule
Before starting the programming procedure, use Tables 5 and 6 to organize your schedule. The preprogrammed
schedule is shown in Table 4. Four time periods are available—WAKE, LEAVE, RETURN, and SLEEP.
Table 5. Your 24-Hour Schedule.
WAKE LEAVE RETURN SLEEP
Program
Repeats
Every 24
Hours
TIME
FAN AUTO ON
H C
TIME
FAN AUTO ON
H C
TIME
FAN AUTO ON
H C
TIME
FAN AUTO ON
H C
WAKE LEAVE RETURN SLEEP
Program Repeats
Every 24 Hours
TIME 6:00 AM
FAN AUTO
H 70 C 78
TIME 8:00 AM
FAN AUTO
H 62 C 85
TIME 5:00 PM
FAN AUTO
H 70 C 78
TIME 10:00 PM
FAN AUTO
H 62 C 75

Trane DELUXE programable XT302C Specifications

General

Brand	Trane
Model	DELUXE programable XT302C
Category	Thermostat
Language	English
