Trane Picco R32-SL16T User Manual

Picco R32 Air/Water heat pumps with axial fans
36
11. TECHNICAL DATA
STANDARD UNIT TECHNICAL SHEET
TECHNICAL SPECIFICATIONS Unit
Picco R32
06A 08A 10
Cooling
Cooling capacity (1)
kW 3,22 / 5,19 / 5,71* 3,74 / 6,14 / 6,65* 4,66 / 7,53 / 8,28*
min/nom/max
Input power (1) kW 1,64 1,97 2,39
E.E.R. (1) W/W 3,16 3,12 3,15
Cooling capacity (2)
kW 5,52 / 6,37 / 6,72* 5,58 / 8,03 / 8,67* 6,22 / 9,50 / 10,4*
min/nom/max
Input power (2) kW 1,30 1,79 2,15
E.E.R. (2) W/W 4,90 4,49 4,41
SEER (5) W/W 4,42 4,51 4,34
Water ow rate (1) L/s 0,25 0,29 0,36
User side heat exchanger pressure drops (1) kPa 3,2 5,3 6,9

Heang capacity (3)
kW 4,47 / 6,13 / 7,48* 4,51 / 7,81 / 9,42* 5,33 / 10,1 / 11,6*
min/nom/max
Input power (3) kW 1,25 1,71 2,28
C.O.P. (3) W/W 4,90 4,57 4,43
Heang capacity (4)
kW 4,29 / 5,97 / 7,03* 4,24 / 7,71 / 8,99* 5,18 / 9,76 / 11,2*
min/nom/max
Input power (4) kW 1,58 2,11 2,80
C.O.P. (4) W/W 3,78 3,65 3,48
SCOP (6) W/W 4,46 4,46 4,53
Water ow rate (4) L/s 0,29 0,37 0,47
User side heat exchanger drops (4) kPa 4,4 8,6 9,7
Energy eciency
Classe A+++/A++ A+++/A++ A+++/A++
water 35°C / 55°C
Compressor
Type Twin Rotary Dc Inverter
Number of compressors 1 1 1
Refrigerant oil (type) ESTER OIL VG74
Oil charge (amount) L 0,62 0,62 1
Refrigerant circuit 1 1 1

Type R32 R32 R32
Refrigerant charge (7) kg 0,97 0,97 2,5
Amount of refrigerant in CO2 tonnes (7) ton 0,7 0,7 1,7
Design pressure (high/low) heat pump mode bar 42,8/1,3 42,8/1,3 42,8/1,3
Design pressure (high/low) chiller mode bar 42,8/3,5 42,8/3,5 42,8/3,5
Fans
Type Motore DC Brushless
Number 1 1 1
Internal heat ex-
changer
Internal heat exchanger type A piastre
N° internal heat exchangers 1 1 1
Water content L 0,6 0,6 1,2
Water circuit
Useful head (1) kPa 74,9 71,0 68,9
Water content of hydronic circuit L 1,14 1,14 1,8
Maximum water side pressure bar 6 6 6
Plumbing ngs inch 1"M 1"M 1"M
Minimum water volume (8) L 40 40 50
Maximum circulator output kW 0,095 0,095 0,075
Maximum circulator absorbed current A 0,66 0,66 0,38
Energy Eciency Index (EEI) circulator ≤ 0,21 ≤ 0,21 ≤ 0,21
Noise level
Sound power level Lw (9) dB(A) 64 64 64
Sound power level Lw (10) dB(A) 62 62 62
Electrical Data
Power supply 230V/1/50Hz
Maximum input power kW 3,4 4,1 4,6
Maximu input current A 15,5 18,7 20,2
Maximum input power with anfreeze kit kW 3,5 4,2 4,8
Maximum input current with anfreeze kit A 15,9 19,1 20,7

Trane Picco R32-SL16T Specifications

General

Brand	Trane
Model	Picco R32-SL16T
Category	Chiller
Language	English
