General Data
Table 1. General data — RAUJ condensing units
Unit Size (tons)
20 25 30 40 50 60 80 100 120
Compressor Data
Type
Scroll
Number of Refrigerant
Circuits
1 1 1 2 2 2 2 2 2
Manifolded Compressor
sizes
(a)
Tons 10-10 10-13.5 15-15 10-10
11.5-
13.5
15-15
15-15-
15
15-15-
20
20-20-
20
Unit Capacity Steps
% 100-50 100-42 100-50
100-75-
50-25
100-73-
46-23
100-75-
50-25
100-83-
66-50-
33-17
100-80-
60-45-
30-15
100-83-
66-50-
33-17
Condenser Fan Data
Type/Drive Type Prop/Direct
Qty
2 3 3 4 6 6 8 12 12
Diameter in 26 26 26 26 26 26 26 26 26
Power/motor
hp
1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
Nominal Total Airflow cfm 14600 20700 20700 26790 36890 40490 56490 73890 76280
Condenser Coil Data
Type
Microchannel
Number of Coils 2 2 2 2 2 2 4 4 4
Size in 42x71 42x71 42x71 59x71 51x96 51x96 59x71 51x96 64x96
Face Area ft
2
41.4 41.4 41.4 58.2 68.0 68.0 116.4 136.0 170.7
Rows/Fin Per Ft. 1/240 1/240 1/240 1/240 1/240 1/240 1/240 1/240 1/240
Storage Capacity
(b)
lbs 18.7 18.7 18.7 23.5 25.0 25.0 47.1 50.0 62.9
Refrigerant Data
(c)
Type
R-410A
Operating Charge
(d)
lbs 11.9 11.8 11.8 22.7 23.4 23.8 57.1 59.1 65.3
Outdoor Air Temperature for Mechanical Cooling
Standard Ambient
Operating Range
(e)
°F 40-125 40-125 40-125 40-125 40-125 40-125 40-125 40-125 40-125
Low Ambient Option
°F 0-125 0-125 0-125 0-125 0-125 0-125 0-125 0-125 0-125
(a)
Circuit 1 compressor manifold sizes shown. For units with 2 circuits, compressor manifold set is the same for circuit 1 and 2.
(b)
Condenser storage capacity is given at conditions of 95°F outdoor temperature, and 95% full.
(c)
Refer to Refrigerant Piping in the Application Considerations section. Condensing units are shipped with nitrogen holding charge only.
(d)
Operating charge is approximate for condensing unit only, and does not include charge for low side or interconnecting lines. Condensing units are shipped
with a nitrogen holding charge only.
(e)
Maximum operating ambient for EVP remote chillers is 115°F.
