General Information
The below hydraulic module operating weight must be added to the RTAD operating
weight.
Table 23 - Hydraulic module additional operating weight - SI units (kg)
Expansion vessel
Pump type Pump model Without 50 litres 80 litres
LRN 208-13/5.5 - LRN 208-14/7.5 400 460 500
SIL 208-16/11 - SIL 208-17/15 455 515 555
JRN 208-13/5.5 - JRN 208-14/7.5 490 550 590
SIL 208-16/11 - SIL 208-17/15 600 660 700
Expansion vessel
LRN 208-13/5.5 - LRN 208-14/7.5 510 570 610
SIL 208-16/11 - SIL 208-17/15 565 625 665
JRN 208-13/5.5 - JRN 208-14/7.5 600 660 700
SIL 208-16/11 - SIL 208-17/15 710 770 810
Hydraulic module addtional operating weight - English units (lbs)
Expansion vessel
Pump type Pump model Without 50 litres 80 litres
LRN 208-13/5.5 - LRN 208-14/7.5 882 1014 1102
SIL 208-16/11 - SIL 208-17/15 1003 1135 1224
JRN 208-13/5.5 - JRN 208-14/7.5 1080 1213 1301
SIL 208-16/11 - SIL 208-17/15 1323 1455 1543
Expansion vessel
LRN 208-13/5.5 - LRN 208-14/7.5 1124 1257 1345
SIL 208-16/11 - SIL 208-17/15 1246 1378 1466
JRN 208-13/5.5 - JRN 208-14/7.5 1323 1455 1543
SIL 208-16/11 - SIL 208-17/15 1565 1698 1786
Single
Single
Dual
Dual
Single
Single
Dual
Dual
RTAD 115 HE - RTAD 125 HE -
RTAD 145 SE - RTAD 150 SE
RTAD 145 HE - RTAD 150 HE -
RTAD 165 SE - RTAD 180 HE
RTAD 115 HE - RTAD 125 HE -
RTAD 145 SE - RTAD 150 SE
RTAD 145 HE - RTAD 150 HE -
RTAD 165 SE - RTAD 180 HE
