Trane S8B1A040M3PSC Installation, Operation And Maintenance

20
S8XB-SVX001-1B-EN
Airflow Tables
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1A040M3PSC
S8X2A040M3PSC
1
SCFM / Watts 592 / 40 342 / 43 93 / 46
2
SCFM / Watts 666 / 48 467 / 56 268 / 65 70 / 74
3
SCFM / Watts 687 / 49 493 / 59 299 / 69 105 / 78
4
SCFM / Watts 938 / 100 788 / 111 638 / 123 488 / 134 338 / 146
5
SCFM / Watts 1006 / 119 870 / 131 733 / 144 597 / 156 461 / 169
6
SCFM / Watts 1068 / 140 944 / 154 820 / 167 696 / 181 573 / 194
7
SCFM / Watts 1174 / 181 1066 / 196 957 / 211 848 / 226 740 / 241
8
SCFM / Watts 1167 / 194 1098 / 219 1029 / 244 960 / 269 891 / 294
9
SCFM / Watts 1556 / 398 1474 / 416 1392 / 435 1310 / 453 1228 / 471
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1B040M2PSC
1
SCFM / Watts 526 / 34
2
SCFM / Watts 744 / 54 533 / 63 322 / 72 110 / 81
3
SCFM / Watts 820 / 68 662 / 81 504 / 94 346 / 106 188 / 119
4
SCFM / Watts 967 / 97 811 / 110 654 / 122 498 / 135 341 / 148
5
SCFM / Watts 997 / 104 840 / 116 687 / 129 533 / 142 380 / 154
6
SCFM / Watts 1052 / 119 911 / 133 771 / 148 630 / 162 490 / 176
7
SCFM / Watts 1099 / 134 968 / 150 837 / 165 706 / 180 575 / 196
8
SCFM / Watts 1168 / 157 1047 / 174 926 / 191 805 / 208 684 / 225
9
SCFM / Watts 1303 / 214 1196 / 233 1088 / 252 981 / 271 874 / 290
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1B060M4PSCA
S8*1B060M4PSCB
S8X2B060M4PSC
1
SCFM / Watts 596 / 38 287 / 42
2
SCFM / Watts 851 / 70 667 / 81 483 / 92 299 / 102 115 / 113
3
SCFM / Watts 1142 / 141 1018 / 156 893 / 172 769 / 187 644 / 203
4
SCFM / Watts 1196 / 160 1079 / 176 961 / 192 844 / 208 726 / 224
5
SCFM / Watts 1362 / 220 1258 / 239 1154 / 257 1050 / 276 946 / 294
6
SCFM / Watts 1416 / 250 1319 / 269 1221 / 288 1124 / 307 1026 / 327
7
SCFM / Watts 1495 / 287 1402 / 307 1309 / 327 1216 / 347 1123 / 367
8
SCFM / Watts 1574 / 337 1487 / 357 1401 / 378 1314 / 399 1228 / 420
9
SCFM / Watts 1983 / 659 1899 / 670 1815 / 680 1730 / 691 1646 / 701
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1B080M4PSCA
S8*1B080M4PSCB
S8X2B080M4PSC
1
SCFM / Watts 552 / 34 160 / 34
2
SCFM / Watts 891 / 82 720 / 93 549 / 105 378 / 117 207 / 129
3
SCFM / Watts 1123 / 141 996 / 157 869 / 173 742 / 189 615 / 205
4
SCFM / Watts 1344 / 224 1240 / 224 1136 / 263 1033 / 283 929 / 302
5
SCFM / Watts 1479 / 290 1384 / 312 1290 / 333 1196 / 354 1102 / 375
6
SCFM / Watts 1583 / 354 1496 / 376 1408 / 398 1321 / 420 1234 / 442
7
SCFM / Watts 1654 / 405 1572 / 428 1491 / 451 1409 / 474 1327 / 496
8
SCFM / Watts 1818 / 542 1739 / 561 1661 / 581 1582 / 600 1503 / 619
9
SCFM / Watts 1926 / 645 1841 / 656 1756 / 667 1670 / 679 1585 / 690
