Trane S8B1A040M3PSC Installation, Operation And Maintenance

S8XB-SVX001-1B-EN
9
Product Specification
MODEL
S8*1A040M3PSC
(a)
S8*1B040M2PSC
(a)
S8*1B060M4PSCA
(a)
S8*1B060M4PSCB
(a)
Type
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
RATINGS
(b)
Input BTUH 40,000 40,000 60,000 60,000
Capacity BTUH (ICS)
(c)
32,300 32,500 48,700 48,700
Temp. Rise (Min. - Max.) °F
30 - 60 30 - 60 30 - 60 30 - 60
AFUE - Rating
(c)
80 80 80 80
Return Air Temp. (Min. - Max.)
°F
55°F - 80°F 55°F - 80°F 55°F - 80°F 55°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT DIRECT
Diameter - Width (in.)
11 X 8 11 X 8 11 X 8 11 X 8
No. Used 1 1 1 1
Speeds (No.)
(d)
CTM - 9 CTM - 9 CTM - 9 CTM - 9
CFM vs. in. w.g.
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
Motor HP
1/2 1/3 3/4 3/4
R.P.M. 1050 1050 1050 1050
Volts / Ph / Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 6.4 4.1 9.2 9.2
COMBUSTION FAN - Type
PSC PSC PSC SP
Drive - No. Speeds
Direct - 1 Direct - 1 Direct - 1 Direct - 1
Motor RPM 3300 3300 3300 3300
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 0.30 0.30 0.30 1.4
Inducer Orifice 1.20 1.15 1.40 1.40
FILTER - Furnished? No No No No
Type Recommended High Velocity High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 14 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in.
VENT PIPE DIAMETER - Min.
(in.)
4 Round 4 Round 4 Round 4 Round
HEAT EXCHANGER - Type
Aluminized Steel Aluminized Steel Aluminized Steel Aluminized Steel
Gauge (Fired)
20 - 19 20 - 19 20 - 19 20 - 19
ORIFICES - Main
Nat. Gas Qty. - Drill Size
2 - 45 2 - 45 3 - 45 3 - 45
L.P. Gas Qty. - Drill Size
2 - 56 2 - 56 3 - 56 3 - 56
GAS VALVE
Redundant - Single
Stage
Redundant - Single
Stage
Redundant - Single
Stage
Redundant - Single
Stage
PILOT SAFETY DEVICE -
Type
120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS - QTY
2 2 3 3
POWER CONN. - V/Ph/HZ
(e)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (Amps)
8.5 5.6 12.0 13.1
Max. Overcurrent Protection
(Amps)
15 15 15 15
PIPE CONN. SIZE (IN.)
1/2 1/2 1/2 1/2
