PKG-SVX14A-EN 25
Maintenance
general
information
Table M-GI-1. Midrange maintenance general data
SCWH030 SCWH050 SCWH075 SCWH100 SCWH120 SCWH150
dimensions, in-lbs.
height 66.93 78.74 78.94 91.54 95.47 95.47
length 31.89 36.41 40.94 65.75 65.75 80.31
depth 22.24 24.01 28.74 29.52 29.52 29.52
weight (shipping / net) 494 / 459 592 / 555 702 / 657 1094 / 1027 1133 / 1063 1249 / 1172
cooling performance
net cooling capacity, btu/h 36000 65290 87570 116986 138204 167303
EER 12.13 12.28 11.6 11.5 11.1 11.3
nominal air flow, cfm 1200 2000 3000 4000 4800 6000
system power, kW 3.0 5.3 7.6 10.2 12.5 14.8
Copeland scroll compressor
quantity 1 1 1 2 2 2
model ZP32 ZP57 ZP83 ZP57 ZP67 ZP83
indoor coil, 3/8" tube size
face area, sq. ft. 3.19 4.98 7.13 12.12 12.12 14.56
rows / fpf 4 / 144 4 / 144 3 / 168 2 / 168 2 / 168 3 / 168
water condenser, tube & tube
water connection, in. 3/4 NPT 3/4 NPT 3/4 NPT 1 1/4 NPT 1 1/4 NPT 1 1/4 NPT
indoor fan, belt-driven
quantity 1 1 2 2 2 2
diameter x width 9 x 9 10 x 10 9 x 9 12 x 12 12 x 12 12 x 12
motor 1 / 0.5 1 / 1.0 1 / 2.0 1 / 2.0 1 / 3.0 1 / 3.0
motor frame size 56 56 56 56 56 56
air filter, 1" throwaway
size / (quantity), in. 14 x 25 (1)
14 x 20 (1) +
20 x 20 (1)
18 x 24 (2)
18 x 24 (3) +
24 x 24 (1)
refrigerant, R-410A, TXV control
refrigerant charge (Ckt 1 / 2), lbs. 3.8 5.4 7.8 5.1 / 5.2 6.5/6.3 7.2/7.2
hot water coil, 2-row, 108 fpf, 1/2" tubes
face area, sq. ft. 1.42 2.08 3.27 6.2 6.2 7.78
Notes:
1. Net cooling capacity is rated at 95°F ambient, 80°F entering dry bulb and 67°F entering wet bulb @ SCFM air condition.
2. EER is rated at ARI condition.
12 x 24 (1) + 24 x 24 (2)
