2. Operation
2.1. Remote Operation
Make sure power is ON
Select the room which needs to be controlled.
Refer section 2.4.2 for dierent functions of remote.
2.2. Manual and Auto Restart Operation
Manual operation can be used temporarily in case remote controller is not available.
Lift Front panel up to an angle, it stays attached with a clicking sound (Refer Figure - 2).
Do not lift front panel at an angle above 60 degrees. Do not apply too much force.
Figure - 2
When you press manual control button (Figure - 3), the unit is switched on at the following default conditions
MODE: COOL FAN SPEED: MEDIUM LOUVER: SWING SET TEMP: 24 °C
Lower the front panel to its initial position.
Manual control button
TSRXXMWXBSFCX Model Series TSRXXDWXBSFCX Model Series
Figure - 3
Use object not more than 5mm in diameter to press manual control button.
To restore remote control operation, use remote control directly.
The Display LED status will not change when unit is operated through manual control button.
•
•
•
Auto Restart Function
Power cut during operation will stop the unit completely.
Unit starts automatically with all previous settings saved in memory function when the power is restored.
Remote will be in sleep condition after 20 second from last key pressed. Remote wakes up from sleep
condition on rst key pressed and does not sends command to AC unit and update just the display settings.
•
•
•
•
•
•
•
•
