Trane TEM4 Series User Manual

18-GF75D1-1C-EN
9
Performance and Electrical Data
Table 3. Air Flow Performance Tables
TEM4B0B24M21SA
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Low
0.1 1140 1078 930 851
0.2 1087 1017 870 796
0.3 1034 955 807 733
0.4 978 894 741 663
0.5 922 834 671 584
0.6 863 774 597 497
0.7 804 715 519 403
• Low = Taps 1–2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
TEM4A0B31M31SB
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Med-Low Low
0.1 1192 1127 1070 995 940
0.2 1148 1079 1021 943 885
0.3 1103 1031 971 890 828
0.4 1057 980 919 834 767
0.5 1009 929 865 775 702
0.6 961 875 810 714 635
0.7 911 820 753 651 564
• Low = Tap 1, Med-Low = Tap 2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
TEM4A0C42S41SC
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208–230 VOLTS
High
Med Low †
0.1 1623 1509 1403
0.2 1583 1465 1357
0.3 1539 1420 1309
0.4 1494 1373 1260
0.5 1450 1326 1211
0.6 1399 1276 1159
0.7 1353 1223 1102
• In downflow applications, airflow must not exceed 1600 cfm due to condensate blowoff.
• Low = Taps 1–3, Med = Tap 4, High = Tap 5
