Trane TKD User Manual

RT-SVX42B-E4 15
Appendix
Table 1 - Exhaust fan performances
Downflow Plate Heat Exchanger (PHE - D)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
125-155-
175
590 n/a n/a n/a n/a n/a n/a n/a n/a n/a 0.3 kW 1167 20 Hz
1340 n/a n/a n/a n/a n/a n/a 0.2 kW 1044 18 Hz 0.3 kW 1241 21 Hz
2090 n/a n/a n/a 0.2 kW 930 16 Hz 0.2 kW 1169 20 Hz 0.3 kW 1335 23 Hz
2840 0.2 kW 889 15 Hz 0.2 kW 1119 19 Hz 0.3 kW 1305 22 Hz 0.4 kW 1447 25 Hz
3590 0.2 kW 1136 20 Hz 0.3 kW 1303 22 Hz 0.4 kW 1449 25 Hz 0.6 kW 1575 27 Hz
4340 0.3 kW 1366 23 Hz 0.5 kW 1486 26 Hz 0.6 kW 1605 28 Hz 0.7 kW 1721 30 Hz
5090 0.5 kW 1581 27 Hz 0.7 kW 1670 29 Hz 0.8 kW 1771 30 Hz 1.0 kW 1884 32 Hz
5840 0.7 kW 1788 31 Hz 0.9 kW 1860 32 Hz 1.1 kW 1952 33 Hz 1.3 kW 2064 35 Hz
6590 1.0 kW 1993 34 Hz 1.3 kW 2058 35 Hz 1.4 kW 2146 37 Hz 1.6 kW 2259 39 Hz
7340 1.4 kW 2204 38 Hz 1.6 kW 2267 39 Hz 1.8 kW 2353 40 Hz 2.0 kW 2463 42 Hz
8090 1.8 kW 2426 42 Hz 2.1 kW 2488 43 Hz 2.3 kW 2568 44 Hz 2.5 kW 2665 46 Hz
8840 2.3 kW 2662 46 Hz 2.6 kW 2718 47 Hz 2.8 kW 2781 48 Hz 3.1 kW 2851 49 Hz
9590 2.9 kW 2907 50 Hz 3.2 kW 2945 51 Hz 3.5 kW 2974 51 Hz 3.8 kW 2995 51 Hz
10340 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
11090 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
11820 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Downflow Plate Heat Exchanger (PHE - D)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
200-250-
265
850 n/a n/a n/a n/a n/a n/a 0.3 kW 756 26 Hz 0.4 kW 910 31 Hz
1920 n/a n/a n/a n/a n/a n/a 0.3 kW 821 28 Hz 0.4 kW 958 33 Hz
2990 n/a n/a n/a 0.3 kW 716 24 Hz 0.3 kW 900 31 Hz 0.5 kW 1021 35 Hz
4060 0.3 kW 642 22 Hz 0.3 kW 839 29 Hz 0.4 kW 990 34 Hz 0.6 kW 1095 37 Hz
5130 0.3 kW 811 28 Hz 0.4 kW 963 33 Hz 0.6 kW 1087 37 Hz 0.8 kW 1182 40 Hz
6200 0.4 kW 974 33 Hz 0.6 kW 1090 37 Hz 0.8 kW 1193 41 Hz 1.1 kW 1280 44 Hz
7270 0.6 kW 1129 38 Hz 0.9 kW 1219 42 Hz 1.1 kW 1307 45 Hz 1.4 kW 1391 47 Hz
8340 0.9 kW 1281 44 Hz 1.2 kW 1352 46 Hz 1.5 kW 1430 49 Hz 1.7 kW 1514 52 Hz
9410 1.3 kW 1431 49 Hz 1.6 kW 1490 51 Hz 1.9 kW 1562 53 Hz 2.2 kW 1647 56 Hz
10480 1.7 kW 1582 54 Hz 2.1 kW 1634 56 Hz 2.4 kW 1703 58 Hz 2.7 kW 1788 61 Hz
11550 2.3 kW 1736 59 Hz 2.6 kW 1784 61 Hz 3.0 kW 1849 63 Hz 3.3 kW 1933 66 Hz
12620 2.9 kW 1896 65 Hz 3.3 kW 1939 66 Hz 3.7 kW 1998 68 Hz 4.0 kW 2075 71 Hz
13690 3.6 kW 2059 70 Hz 4.0 kW 2093 71 Hz 4.4 kW 2141 73 Hz n/a n/a n/a
14760 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
15830 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
16920 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
