4 RT-SVX42B-E4
Installation
Cut the cable tie and prepare the cables at
the border of the ERM to ease the cable
installation into the rooftop front side.
Mount and use the delivered lifting device
for ERM handling as shown in Figure 2.
Figure 2 -
Energy Recovery Module
(ERM) preparation
Use the provided gasket inside the rooftop
unit and fix it to the ERM internal edge as
described in Figure 1.
Figure 1 -
