17
11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
CG-SVU007D-GB
Exemple of hourly scheduling
00:00 03:00 06:00 09:00 12:00 15:00 18:00 21:00 00:00
Zone #1 “Start
CSP 10°C”
Zone #2 “Start
CSP 7°C”
Zone #3 “Start
CSP 10°C”
Zone #4 “Start
CSP 15°C”
“Unit active
cooling setpoint”
15°C 15°C 10°C 7°C 7°C 7°C 10°C 15°C 15°C
Example of hourly setpoint scheduling where unit is delivering 15°C water during the night and 7°C during peak
period of the day (from 9:00 to 15:00). Occupied zone from 6:00 to 21:00.
Configuration menu
Shows and allows modification of unit configuration with 2 user levels (Local technician and Trane service
technician):
Local technician (by default password = 0005) allows to:
Show status display version application
Modification of pump timers, freeze protection and other limits
Force defrost cycle
Show status of digital and analog inputs/outputs,
Manual override of expansion valve.
Modification of local technician password.
User interface display
