22 BAS-SVX40B-EN
Establishing the Network
WCIs as Zone Sensor Receivers
On a WCI that functions as a zone sensor receiver, observe the green SNSR LED illuminate to
confirm association with the wireless zone sensor (see Figure 13).
Note: To set up the addressing for this function, see “Setting Wireless Zone Sensor Receiver
Addressing,” p. 12.
Figure 13. Wireless zone sensor/receiver association
Notes: To observe the radio signal strength between the sensor and receiver, press theTest
button on the sensor.The wireless display sensor shows the signal strength on the
display. For more information about the wireless zone sensor, see the current edition of
Wireless Sensors: Installation, Operation, and Maintenance (BAS-SVX04).
OPEN NET
GRP NET
NWK
SNSR
RX LINK
CRD
