page 14 824 User Guide
To change Periods select: Home Screen > Menu > Schedules & Presets >
Custom Schedule > Select Schedule Time
Changing Period Start or End Times
1. Select anywhere in the Period to make it
active. Other Periods will dim and the Start
and End times for this Period will be in a
black box.
2. Select the TIME START or TIME END and
adjust the time using the UP and DOWN
arrows. NOTE: The XL824 uses intelligent
technology and will not allow setting an
illogical start or end time. Periods must be
at least 30 minutes in duration.
Changing Period Set Points
1. Select the active Period’s Cooling or Heating
Set Point.
2. Adjust the Set Point using the UP or DOWN
arrows.
Changing the Period Name
1. Select the PERIOD NAME (Wake, Away,
etc.).
2. Select a predened name or select NEW
and select NEXT.
3. If selecting a new name, enter the name
using the on-screen keyboard.
4. Select NEXT.
When all changes have been made, select APPLY
to save and exit, or select CANCEL to discard all
changes that were made to this Schedule.
Changing Periods
Schedule Mon Tue Wed Thu Fri Sat Sun
6:00 am 8:00 am 6:00 pm 10:00 pm
78º
70º
85º
78º
70º
82º
62º62º
Wake
Time
Start
Time
End
Away Home Sleep
Apply Cancel
Select Apply to save
changes and exit
Adjust Start and
End Times
Press in the red or blue area, then adjust
the Set Point using the up
and down arrows
Press in the gray area
to rename the period
Use the Up and
Down Arrows to
change values
To Next Page
