INTRODUCTION

You have purchased a two post 9,000 pound lift that is a great value for the price. Please

read this manual thoroughly before starting any installation. You will find information not

only in install but also safety, maintenance and troubleshooting that should also be

understood.

If properly taken care of, this lift should be useful to you for a long time. Pay attention to

safety and maintenance as they play an important part in making your lift last a long time.

Call us if you have any questions or need any repair parts for this lift.

Thoroughly read this manual before operating the lift. Always display this manual in a

conspicuous location near the lift. Personal injury and property damage incurred due to

non-compliance this these safety instructions are not covered by warranty.

LIFT SPECIFICATIONS

 9,000 Pound (NTO-9AE & NTO09A) 10,000 Pound (NTO-10A) Max Capacity

 Two Post Overhead Verisymmetric

 Triple Arm Length (Max 51.5”, Min 29”)

 Double Arm Length (Max 41.5” Min 27”)

 Rubber Door Protectors on columns

 Chain Lifting – Stronger than cable used on other lifts

 Hydraulic Power Unit - 220 V, 1PH, 60Hz (Standard), 3 HP

 Lifting Time 40-50 Seconds

 Cable Equalization

 Locking Method: Dual Point Release

 Electric Safety Cutoff Bar

 Distance between columns: 109”

 Distance to outside of columns: 124”

 Drive through width at carriage: 100”

 Overall width including power unit: 145”

 Height Under Arm at top of Stroke: 73.5”

 Height under Arm at top Lock 67”

 12 Sets of Drop In Adapters (1.5”, 3”, 6”)

 Height to top of pad when lift fully Lowered: 4.5”

 Overall Lift Height: 142.5”

 Distance outside of base plates: 133”

 Shipping Weight: 1407 Pounds
