Parts Identification
19
Parts Identification - Continued
6
78
5
12
910
3
11
4
12
13
1. Fuel tank
2. Coolant pressure cap (under fuel tank)
3. Fuel filler cap
4. Front brake fluid reservoir
5. Front brake lever
6. Front fork
7. Oil filler plug
8. Rear brake fluid reservoir (behind cover)
9. Oil level sight glass
10. Rear brake pedal
11. Drive chain
12. Rear suspension unit
13. Muffler
