Triumph Speed Triple 1200 RR 2021 - Spring Preload Adjustment; Compression Damping Adjustment

MAINTENANCE
152
Spring Preload Adjustment
The Speed Triple 1200 RS spring preload
adjusters are located at the top of each
fork.
1
1. Spring preload adjusters
To change the spring preload:
▼ Rotate the spring preload adjuster
clockwise to increase preload, or
counterclockwise to decrease
preload.
▼ Always count the number of
clockwise turns from the fully
counterclockwise position and set
both forks to the same settings.
Compression Damping Adjustment
The Speed Triple 1200 RS compression
damping adjuster is located at the top
of the left hand fork.
1
1. Compression damping adjuster
To change the compression damping
force:
▼ Using a 0.12 in (3 mm) Allen key,
rotate the adjuster clockwise to
increase, or counterclockwise to
decrease.
▼ Always count the number of clicks
from the fully clockwise position
noting that the first stop (click
position) is counted as 1.
