Trojan APEX 100 User Manual

7
PARTS LIST
No. Description Qty
1 Main Frame 1
2 Crank 1
3 Front Base 1
3a Elliptical End Cap 4
4 Rear Base 1
5 Handlebar Support 1
6 Handlebar 1
7 Saddle Support 1
8 Saddle 1
8a Saddle Washer 3
8b Saddle Nut 3
9 Console Base 1
10 Console 1
11 Left Pedal 1
12 Right Pedal 1
13 Triangle Knob 1
14 Sleeve 1
15 Triangle Tension Control 1
15a Triangle Control Cable 1
16 Triangle Control Base 1
17 Quadrate Bolt (M8 x 70) 2
18
Arc Washer (Ø8)
8
18a
Flat Washer (Ø8)
2
19 Ball Nut (M8) 4
20 Quadrate Bolt (M8 x 40) 2
21 Hex Recessed Bolt (M8 x 20) 6
23
Spring Washer (Ø8)
6
24
Cross Screw (ST 4.2 x 16)
1
No. Description Qty
25 Tapping Screw (ST 4.2 x 16) 2
26 Tension Cable Connection 1
27a, b, c Meter Cable 1
28a Left Cover 1
28b Right Cover 1
29 Belt 1
30 Nylon Bushing 2
31 Big Special Washer 4
32 Small Locking Plate Assembly 1
33 Round Magnet 1
34 Cable Plug 1
35 Wheel 1
36 Split Pin 2
37 Sensor 1
38 Cross Countersunk Head Screw (M5 x 16 1
39 Cross Pan Head Screw (M5 x 16) 2
40 Cross Pan Head Tapping Screw (ST4.2 x 19) 5
41
Cross Countersunk Head Tapping Screw
(ST2.9 x 9.5)
2
42 Crank Cap 2
