14
10309
ASSEMBLY STEPS
5
6
NO Description Qty
58 Hex Bolt M10 x 60 mm 3
67 M10 Washer 6
70 M10 Nylon Nut 3
73 Bolt M10 x 25 mm 2
NO Description Qty
62 Hex Bolt M8 x 50 mm 2
65 Hex Bolt M8 x 15 mm 4
68 M8 Washer 6
#13M07T017 Power Gym 150 UM OL.indd 14 2013/07/31 10:30 AM
