10253 - 15
No. Description Qty No. Description Qty
001 Main Frame 1 034 Cap Nut M10 4
002 Handlebar Ø25 x 1.5 1 035 Bolt M10 x 57 4
003 Handlebar Post Ø50 x 1.5 1 036 Big Curved Washer Ø10 4
004 Rear Stabilizer Ø50 x 1.5 1 037 Curved Washer Ø20 x Ø8 x1.5 4
005 Flywheel Ø230,4kg 1 038 Washer Ø8 3
006 Front Stabilizer Ø50 x 1.5 1 039 Bolt M8 x 10 1
007 Tension Control Knob 1 040 Pan Head Phillips Self Tapping Screw ST4.2 x 25 6
008 Round Knob M16 1 041 Pan Head Phillips Self Drilling Screw ST4.2 x 25 4
009 Belt 320/J6 1 042 Locknut M8 3
010 Computer 1 043 Bolt M8 x 30 1
011 Nut M10 x 1 2 044 Pressing Belt Wheel 1
012 Bushing Ø50 x 1.5 1 045 Bearing 6000zz 2
013 Left Cover 1 046 Big Curved Washer Ø5 x 1.5 1
014 Right Cover 1 047 Bolt M5 x 10 2
015 Screw ST2.9 x 10 2 048 Washer Ø40 x Ø24 x 3.0 1
016 Ring II 1 049 Handlebar End Cap Ø25 2
017 Axle Sleeve 15/16” 1 050 Handlebar Foam Grip Ø30 x Ø24 x 455 2
018 Nut 7/8” 1 051 Screw ST4.2 x 20 2
019 Belt Pulley with Crank 240J6 1 052 Screw M6 x 10 1
020 Left Foot Pedal YH-30X 1 053 Hand Pulse Sensor with Wire L=750 mm 2
021 Right Foot Pedal YH-30X 1 054 Tension Cable L=600 mm 1
022 Axle Bush 2 055 Washer Ø6 x 1.5 4
023 Ball Bearing 2 056 Washer Ø10.2 x Ø14 x1.0 2
024 Bolt M8 x 15 S6 6 057 Bolt M5 x 45 1
025 Seat Post 1 058 Axle Sleeve II 7/8” 1
026 Sensor with Wire L=450 mm 1 059 Middle Section Sensor Wire L=800 mm 1
027 Seat Cushion DD-982AT 1 060 Decoration Cover 2
028 Front Stabilizer End Cap Ø50 2 61 Transport Wheel 2
029 Rear Stabilizer End Cap Ø50 2 62 Bolt M6 x 48 2
030 U Bracket 2 63 Nylon Nut M6 2
031 Adjustable Bolt M6 x 36 2 64 Curved Washer Ø16 x Ø8 x 1.5 2
032 Hex Nut M6 2 65 Plastic Sleeve 1
033 Spring Washer Ø6 2
10. PARTS LIST
