TSC PEX-1131 Series User Manual

- 42 -
Head Close
This option is used to set the action of the media when
you close the print head.
Selections
Description
Feed
Print engine will advance one label
Calibration
Print engine will calibration the sensor
levels, determine length and feed label
Length
Print engine determine length and feed
label
No Motion
Print engine will not move media
No Motion
Label Top
This option is used to adjust print position vertically on
the label. The range is -120 to +120 dots.
0
Left Position
This option is used to adjust print position horizontally on
the label. The range is -9999 to +9999 dots.
0
Reprint Mode
When reprint mode is enabled, you can reprint the last
label by pressing button on control panel.
Disabled
Format Convert
Selects the bitmap scaling factor. The first number is the
original dots per inch (dpi) value; the second, the dpi to
which you would like to scale.
None
Note: If printing from enclosed software/driver, the software/driver will send out the
commands, which will overwrite the settings set from the panel.
