Uberhaus 10625002 User Manual

9
PARTS LIST
Please refer to the Schematic Drawing on the next page.
No. DESCRIPTION Qty No. DESCRIPTION Qty
1 S-TYPE BODY 1 19 POWER CORD 1
2 SCREW 4 20 SCREW 2
3 THERMOSTAT 1 21 CORD CLAMP HOLDER 1
4 FRONT COVER 1 22 CORD CLAMP 1
5 SCREW 2 23 SCREW 2
6 THERMOSTAT KNOB 1 24 CERAMIC ASSY 1
7 CONTROL PANEL 1 25 SCREW 1
8 HANDLE 1 26 SCREW 1
9 SCREW 1 27
MANUAL SETTING
THERMAL CUT-OUT 1
10 SCREW COVER 1 28 SCREW 1
11 SCREW 4 29 HEATING TUBE 1
12
POWER SWITCH
COVER 1 30 PLUG WASHER 1
13 PANEL 1 31 FLOWER SCREW 4
14 POWER INDICATOR 1 32 CASTER 1
15 SCREW 3 33 U-TYPE BUTTON 2
16 BUSHING 1 34
RESETTABLE
THERMOSTAT 1
17 CORD WRAP 1 35 POWER SWITCH 2
18 SCREW 2 36 TIP-OVER SWITCH 1
